Signal Characteristics
250 kHz to 13, 20, 31.8, 40, 50 or 67 GHz, operational to 70 GHz (.001 Hz resolution), and 10 MHz to 20 GHz (Option 521 only)
Extendable to 75, 90, 110, 140, 170, 220, or 325 GHz
+23 dBm @ 20 GHz, +17dBm @ 40 GHz, +14 dBm @ 67 GHz output power (typ); > +30 dBm (typ) with Option 521
Industry’s best SSB phase noise
Modulation
AM, FM, ØM, pulse, and scan
8 ns rise/fall times and 20 ns pulse width (typ)
Dual internal function generators: sine, square, triangular, ramp, and noise
Sweep
Step, list, and ramp sweep (frequency and power)
Source control using PSA Series spectrum analyzer
Agilent 8757D scalar network analyzer code compatible
Automation and Communication Interface
10BaseT LAN and GPIB
SCPI and IVI-COM drivers
Backwards compatible with all PSG signal generators
