Tektronix TCP0030A Inventory Listings and Pricings

		PRODUCT	RESELLER	LIST PRICE	NEW PRICE	USED PRICE
48	TCP0030A	Tektronix TCP0030A DC to 120MHz 30A Current Probe	Electro Rent (1)	$5,420	-	$3,810	30% off!	GET QUOTE
35	TCP0030A	Tektronix TCP0030A Probe, AC/DC Current; 30 Amp DC, DC TO 120 MHZ; with TekVPI Interface; Certificate of Traceable Calibration Standard	Continental Resources	-	$5,530	$3,795		GET QUOTE
35	TCP0030A-O	Tektronix TCP0030A-O Tektronix TCP0030A Current Probe	Continental Resources	-	-	$3,500		GET QUOTE
154	TCP0030A	Tektronix TCP0030A The TCP0030A is a Current Probe from Tektronix. Current Probes are an integral part of any electrical power testing toolbox to ensure accurate measurements, reliability, and safety. Purchase a current probe set with your oscilloscope. Probes can use pulse waveforms to test components without removing them from circuits with in-circuit capabilities. Choose the probe that complements your system. We carry new and used current probes from major industry brands.	ValueTronics International, Inc.	-	$5,260	-		GET QUOTE
23	TCP0030A	Tektronix TCP0030A Tektronix TCP0030A Current Probe, AC/DC, DC to 120 MHz, 30 A DC	Axiom Test Equipment (2)	-	-	-		GET QUOTE
481	TCP0030A-NEW	Tektronix TCP0030A-NEW Probe: AC/DC Current; 30 Amp DC: DC TO 120 MHZ; with TekVPI Interface; Certificate of Traceable Cali	Extended Network	-	-	$4,200		GET QUOTE
298	TCP0030A	Tektronix TCP0030A Tektronix_TCP0030A: AC/DC 30A 1mA Current Probe (0600)	Nubicom Inc.	-	-	$3,900		GET QUOTE
481	TCP0030A	Tektronix TCP0030A Probe AC/DC Current; 30 Amp DC DC TO 120 MHZ; with TekVPI Interface; Certificate of Traceable Calibration Standard	Extended Network	-	$4,410	-		GET QUOTE

Please select the Condition of the item

✖

Add To Cart

Quote Cart Updated

Item has been added to your quote cart

View Quote Cart Continue Browsing Continue Browsing

Additional Information

✖

Tektronix TCP0030A Options and Accessories

PRODUCT	MODEL	DESCRIPTION	LIST PRICE	TYPE
TCP0030A	D1	Calibration Data Report	$44.00	Option
TCP0030A	C3	Calibration service 3 years.Includes traceable calibration or functional verification where applicable for recommended calibrations. Coverage includes the initial calibration plus 2 years calibration coverage.	$410.00	Service
TCP0030A	C5	Calibration service 5 years.Includes traceable calibration or functional verification where applicable for recommended calibrations. Coverage includes the initial calibration plus 4 years calibration coverage.	$750.00	Service
TCP0030A	D3	Calibration Data Report 3 Years (with Option C3)	$82.00	Service
TCP0030A	D5	Calibration Data Report 5 Years (with Option C5)	$150.00	Service
TCP0030A	R3	Standard Warranty Extended to 3 Years. Covers parts labor and 2-day shipping within country. Guarantees faster repair time than without coverage. All repairs include calibration and updates. Hassle free - a single call starts the process	$397.00	Service
TCP0030A	R5	Standard Warranty Extended to 5 Years. Covers parts labor and 2-day shipping within country. Guarantees faster repair time than without coverage. All repairs include calibration and updates. Hassle free - a single call starts the process	$794.00	Service

Tektronix TCP0030A Product Overview

( own it? please share by Add Your Own Review! )

TCP0030A is a high-performance, easy-to-use AC/DC current probe designed for use and direct connection to oscilloscopes with the TekVPI™ probe interface. This AC/DC current measurement probe provides greater than 120 MHz of bandwidth with selectable 5 A and 30 A measurement ranges. It also provides exceptional low-current measurement capability and accuracy to current levels as low as 1 mA, important for meeting today's challenging current measurement needs.

Key features

Easy-to-use and accurate AC/DC current measurements
Intelligent communication with TekVPI™ oscilloscopes provides:
- Units scaling and readout. Automatic, on-screen readout of amps and magnitude. Manual setup is not required. Hand calculation from volts to amps is unnecessary
- Push button degauss and Autozero functionality
- Probe status and diagnostic indicator LEDs
- Remote GPIB/USB probe control
Split-core construction allows easy circuit connection
High accuracy with typically less than 1% DC gain error
Low noise and DC drift
3rd party safety certification

Key performance specifications

DC to >120 MHz bandwidth
30 A RMS maximum current capability
50 A peak pulse current capability
High accuracy with typically less than 1% DC gain error
Accurately measures current levels as low as 1 mA

Applications

Power supplies
Semiconductor devices
Power inverters/converters
Electronic ballasts
Industrial/consumer electronics
Mobile communications
Motor drives
Transportation systems
