• Signal analysis capabilities with up to 80 MHz analysis bandwidth, +/-0.19 dB absolute amplitude accuracy, -155 dBm DANL, -118 dBc/Hz phase noise at 10 kHz offset, and 81 dB W-CDMA ACLR dynamic range
• Address application-specific requirements with capabilities including 16 measurement personalities and one-button measurement simplicity

Performance
+/-0.19 dB absolute amplitude accuracy
-155 dBm (-168 dBm w/preamp) displayed average noise level (DANL)
-118 dBc/Hz phase noise at 10 kHz offset
81 dB W-CDMA ACLR dynamic range

Analysis bandwidth
Standard 10 MHz analysis bandwidth
Optional 40 or 80 MHz analysis bandwidth to capture and measure complex signals.
-78 dB (nominal) third order intermodulation for 40 or 80 MHz analysis bandwidth
Up to 300 MHz analysis bandwidth for calibrated VSA measurements

Flexibility
Flexible platform with 16 optional, easy-to-use built-in measurement personalities and hardware options
PowerSuite enables one-button power measurements for over 20 radio formats PSA PowerSuite One-Button Power Measurements
