Features & Benefits

• Analog Bandwidth: 12.5 GHz
• Sample Rate: 50 GS/s to 100 GS/s
• Record length: 62.5M points to 250M points
• 4 Analog Channels and 16 Digital Channels
• Four-channel Simultaneous Performance
• 16 Logic Channels with 80 ps Timing Resolution for Debug of digital analog signals
• Unique iCapture® capability enables viewing analog characteristics of digital channels with single probe connection
• 6.25 GB/s Real-time Serial Trigger assures triggering on the first instance of a specified NRZ or 8b/10b pattern to allow isolation of pattern-dependent effects
• Application support for High-speed serial industry standards, wideband RF, power supplies, and memory
• Superior signal integrity and excellent signal-to-noise ratio
• Pinpoint® triggering minimizes time spent trying to acquire problem signals for efficient troubleshooting and shortened debug time
• Visual Trigger precisely qualify triggers and find unique events in complex waveforms
• USB host ports on both front and rear panel
• Integrated 10/100 Ethernet port for network connection
• Video Out port to export the oscilloscope display to a monitor or projector

Application Support

• High-speed serial industry standards compliance
• SignalVU® RF and vector signal analysis
• DDR memory bus analysis

Applications

• Design verification including signal integrity, jitter, and timing analysis
• Design characterization for high-speed, sophisticated designs
• Certification testing of serial data streams for industry standards
• Memory bus analysis and debug
• Prototype turn-on and power supply verification
• Research and investigation of transient phenomena
• Production testing of complex systems
• Spectral analysis of transient or wide-bandwidth RF signals
