Yokogawa CL255 Clamp-on Tester (True RMS, AC/DC 2000A) Current Tester





product image

  •
Manufacturer: Yokogawa Product Series: CL Series
Base Model: CL255 Total Listings: 0 Units
Description: Clamp-on Tester (True RMS, AC/DC 2000A) Current Tester
Data Sheet PDF: Download CL255 Data Sheet
Average New CL255 Price: Get Quote
Average Used CL255 Price: Get Quote
Estimated Rental Rate :
Get Quote
Average Lease Rate : Get Quote
CL255 Calibration Price: Get Quote
* Rates depend on unit configuration, duration of the rental, and inventory levels and will vary from TestUnlimited estimates. Rental Tips
**Lease rate estimates are based on "A" credit rating, 60-month term. Unit configuration and inventory levels will cause the rate to vary from the estimate above. Benefits of Leasing
Quote Now !













Add message to dealer?



Quote CL255 Now !

AVAILABLE INVENTORY

PRODUCT OPTIONS

PRODUCT SPECIFICATIONS

PRODUCT OVERVIEW

VIDEO & LITERATURES

USER REVIEWS

FORUM

GET QUOTE

Yokogawa CL255 Inventory Listings and Pricings
Filter by:         APPLY FILTER

No available dealer listings for CL255.
  Please select the Condition of the item
Yokogawa CL255 Product Overview
( own it? please share by Add Your Own Review! )

Key Features & Specifications

Yokogawa CL255 Clamp-on Tester (True RMS, AC/DC 2000A)

Specifications

  • Description True RMS ACA, DCA, ACV, DCV
  • Method of detection True RMS
  • Display LCD (Digital display: 3999 counts)
  • DC Current Range 400/2000A
  • DC Current Resolution 0.1A
  • Response Time Approx. 1 second (on DC current/voltage range)
  • Approx. 2 seconds (AC current/voltage range, resistance range)
  • Range Switching Auto-range
  • Operating temperature and humidity 0 - 40°C, 85% RH or less (no condensation)
  • Influence of external magnetic field 4A or less at 400 A/m
  • Influence of conductor position ±(1.5% rdg + 3 dgt) or less
  • Safety Standard Conforms EN61010-1, EN61010-2-031, EN61010-2-032
  • Circuit voltage 1000 Vrms or less
  • Withstanding voltage 5.55 kV AC for one minute
  • Power Supply 6F22 (006P) 9V x 1
  • 6LR61 x 1
  • Battery Life Approx. 15 hours (continuous)
  • Consumed current Approx. 15 mA
  • Sleep Function Automatically powered down in about 10 minutes after the last switch operatio
  • Diameter of measurable conductor 55 mm at maximum
  • Dimensions Approx. 105 (W) x 250 (H) x 49 (D) mm
  • Weight Approx. 540 g
  • Accessories Batteries, carrying case (93034)
  • Output plug (98012)
  • Test Lead (98011)
  • User's manual (IM CL250)
  • Peak Hold On current / Voltage range

Description

  • True RMS display
  • AC/DC current measurements with current ranges up to 2000A
  • AC/DC voltage and resistance measurements
  • DC output
  • 55mm in diameter of measurable conductor
  • Sleep function
  • Data hold function
  • Approved for conformity to safety standards EN61010-1,EN61010-2-031, EN61010-2-032 (CAT. III 600 V, CAT. II 1000 V)

More details on Yokogawa website
Yokogawa CL Series
PRODUCT IDPRODUCT RATINGMANUFACTURERBASE MODELCATEGORYDESCRIPTION
5387 YokogawaCl120Current TestersMini Clamp-on Tester (200A): AC 20/200A
5388 YokogawaCL150Current TestersClamp-on Tester (ACA, ACV, DCV, OHM, 2000A)
5389 YokogawaCL155Current TestersClamp-on Tester (AC, True RMS, 2000A)
5390 YokogawaCL220Current TestersClamp-On Tester (AC/DC 300A)
5391 YokogawaCL235Current TestersClamp-on Tester (True RMS, AC/DC 600A/1000A)
5392 YokogawaCL250Current TestersClamp-on Tester (AC/DC 2000A)
5393 YokogawaCL255Current TestersClamp-on Tester (True RMS, AC/DC 2000A)
5394 YokogawaCL320Current TestersClamp-on Tester (Leakage Current, 200A)
5395 YokogawaCL340Current TestersClamp-on Tester (Leakage Current, 400A)
5396 YokogawaCL345Current TestersClamp-on Tester (Leakage Current, True RMS, 400A)
5397 YokogawaCL360Current TestersClamp-on Tester (Leakage Current, 100A)
5398 YokogawaCL420Current TestersClamp-on Process Meter (DC mA Current)
